4.16 虚拟内存管理（Virtual Memory Management）

int deviceSupportsVmm;
CUresult result = cuDeviceGetAttribute(&deviceSupportsVmm, CU_DEVICE_ATTRIBUTE_VIRTUAL_MEMORY_MANAGEMENT_SUPPORTED, device);
if (deviceSupportsVmm != 0) {
    // `device` 支持虚拟内存管理
}

int deviceSupportsFabricMem;
CUresult result = cuDeviceGetAttribute(&deviceSupportsFabricMem, CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_FABRIC_SUPPORTED, device);
if (deviceSupportsFabricMem != 0) {
    // `device` 支持 Fabric 内存
}

int deviceSupportsMultiCast;
CUresult result = cuDeviceGetAttribute(&deviceSupportsMultiCast, CU_DEVICE_ATTRIBUTE_MULTICAST_SUPPORTED, device);
if (deviceSupportsMultiCast != 0) {
    // `device` 支持多播对象
}

CUmemGenericAllocationHandle allocatePhysicalMemory(int device, size_t size) {
    CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR;
    CUmemAllocationProp prop = {};
    prop.type = CU_MEM_ALLOCATION_TYPE_PINNED;
    prop.location.type = CU_MEM_LOCATION_TYPE_DEVICE;
    prop.location.id = device;
    prop.requestedHandleType = handleType;

    size_t granularity = 0;
    cuMemGetAllocationGranularity(&granularity, &prop, CU_MEM_ALLOC_GRANULARITY_MINIMUM);

    // 确保大小符合该分配的粒度要求
    size_t padded_size = ROUND_UP(size, granularity);

    // 分配物理内存
    CUmemGenericAllocationHandle allocHandle;
    cuMemCreate(&allocHandle, padded_size, &prop, 0);

    return allocHandle;
}

CUmemGenericAllocationHandle allocatePhysicalMemory(int device, size_t size) {
    CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_FABRIC;
    CUmemAllocationProp prop = {};
    prop.type = CU_MEM_ALLOCATION_TYPE_PINNED;
    prop.location.type = CU_MEM_LOCATION_TYPE_DEVICE;
    prop.location.id = device;
    prop.requestedHandleType = handleType;

    size_t granularity = 0;
    cuMemGetAllocationGranularity(&granularity, &prop, CU_MEM_ALLOC_GRANULARITY_MINIMUM);

    // 确保大小符合该分配的粒度要求
    size_t padded_size = ROUND_UP(size, granularity);

    // 分配物理内存
    CUmemGenericAllocationHandle allocHandle;
    cuMemCreate(&allocHandle, padded_size, &prop, 0);

    return allocHandle;
}

CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR;
CUmemGenericAllocationHandle handle = allocatePhysicalMemory(0, 1<<21);
int fd;
cuMemExportToShareableHandle(&fd, handle, handleType, 0);

CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_FABRIC;
CUmemGenericAllocationHandle handle = allocatePhysicalMemory(0, 1<<21);
CUmemFabricHandle fh;
cuMemExportToShareableHandle(&fh, handle, handleType, 0);

int ipcSendShareableHandle(int socket, int fd, pid_t process) {
    struct msghdr msg;
    struct iovec iov[1];

    union {
        struct cmsghdr cm;
        char* control;
    } control_un;

    size_t sizeof_control = CMSG_SPACE(sizeof(int)) * sizeof(char);
    control_un.control = (char*) malloc(sizeof_control);

    struct cmsghdr *cmptr;
    ssize_t readResult;
    struct sockaddr_un cliaddr;
    socklen_t len = sizeof(cliaddr);

    // 构造要发送此可共享句柄的客户端地址
    memset(&cliaddr, 0, sizeof(cliaddr));
    cliaddr.sun_family = AF_UNIX;
    char temp[20];
    sprintf(temp, "%s%u", "/tmp/", process);
    strcpy(cliaddr.sun_path, temp);
    len = sizeof(cliaddr);

    // 向客户端发送相应的可共享句柄
    int sendfd = fd;

    msg.msg_control = control_un.control;
    msg.msg_controllen = sizeof_control;

    cmptr = CMSG_FIRSTHDR(&msg);
    cmptr->cmsg_len = CMSG_LEN(sizeof(int));
    cmptr->cmsg_level = SOL_SOCKET;
    cmptr->cmsg_type = SCM_RIGHTS;

    memmove(CMSG_DATA(cmptr), &sendfd, sizeof(sendfd));

    msg.msg_name = (void *)&cliaddr;
    msg.msg_namelen = sizeof(struct sockaddr_un);

    iov[0].iov_base = (void *)"";
    iov[0].iov_len = 1;
    msg.msg_iov = iov;
    msg.msg_iovlen = 1;

    ssize_t sendResult = sendmsg(socket, &msg, 0);
    if (sendResult <= 0) {
        perror("IPC failure: Sending data over socket failed");
        free(control_un.control);
        return -1;
    }

    free(control_un.control);
    return 0;
}

int ipcSendShareableHandle(HANDLE *handle, HANDLE &shareableHandle, PROCESS_INFORMATION process) {
    HANDLE hProcess = OpenProcess(PROCESS_DUP_HANDLE, FALSE, process.dwProcessId);
    HANDLE hDup = INVALID_HANDLE_VALUE;
    DuplicateHandle(GetCurrentProcess(), shareableHandle, hProcess, &hDup, 0, FALSE, DUPLICATE_SAME_ACCESS);
    DWORD cbWritten;
    WriteFile(handle->hMailslot[i], &hDup, (DWORD)sizeof(hDup), &cbWritten, (LPOVERLAPPED)NULL);
    CloseHandle(hProcess);
    return 0;
}

MPI_Send(&fh, sizeof(CUmemFabricHandle), MPI_BYTE, 1, 0, MPI_COMM_WORLD);

int ipcRecvShareableHandle(int socket, int* fd) {
    struct msghdr msg = {0};
    struct iovec iov[1];
    struct cmsghdr cm;

    // 使用 union 确保控制数组满足对齐要求
    union {
        struct cmsghdr cm;
        // QNX 上不能使用此写法，因为 QNX 的 CMSG_SPACE 会调用 __cmsg_alignbytes，
        // 而 __cmsg_alignbytes 是运行时函数而非编译期宏
        // char control[CMSG_SPACE(sizeof(int))]
        char* control;
    } control_un;

    size_t sizeof_control = CMSG_SPACE(sizeof(int)) * sizeof(char);
    control_un.control = (char*) malloc(sizeof_control);
    struct cmsghdr *cmptr;
    ssize_t n;
    int receivedfd;
    char dummy_buffer[1];
    ssize_t sendResult;
    msg.msg_control = control_un.control;
    msg.msg_controllen = sizeof_control;

    iov[0].iov_base = (void *)dummy_buffer;
    iov[0].iov_len = sizeof(dummy_buffer);

    msg.msg_iov = iov;
    msg.msg_iovlen = 1;
    if ((n = recvmsg(socket, &msg, 0)) <= 0) {
        perror("IPC failure: Receiving data over socket failed");
        free(control_un.control);
        return -1;
    }

    if (((cmptr = CMSG_FIRSTHDR(&msg)) != NULL) &&
        (cmptr->cmsg_len == CMSG_LEN(sizeof(int)))) {
        if ((cmptr->cmsg_level != SOL_SOCKET) || (cmptr->cmsg_type != SCM_RIGHTS)) {
        free(control_un.control);
        return -1;
        }

        memmove(&receivedfd, CMSG_DATA(cmptr), sizeof(receivedfd));
        *fd = receivedfd;
    } else {
        free(control_un.control);
        return -1;
    }

    free(control_un.control);
    return 0;
}

int ipcRecvShareableHandle(HANDLE &handle, HANDLE *shareableHandle) {
    DWORD cbRead;
    ReadFile(handle, shareableHandle, (DWORD)sizeof(*shareableHandles), &cbRead, NULL);
    return 0;
}

MPI_Recv(&fh, sizeof(CUmemFabricHandle), MPI_BYTE, 1, 0, MPI_COMM_WORLD);

CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR;
cuMemImportFromShareableHandle(handle, (void*) &fd, handleType);

CUmemAllocationHandleType handleType = CU_MEM_HANDLE_TYPE_FABRIC;
cuMemImportFromShareableHandle(handle, (void*) &fh, handleType);

CUdeviceptr ptr;
// `ptr` 保存所保留虚拟地址范围的起始地址。
CUresult result = cuMemAddressReserve(&ptr, size, 0, 0, 0); // alignment = 0 表示默认对齐

CUdeviceptr ptr;
// `ptr`：之前由 cuMemAddressReserve 保留的地址范围中的地址。
// `allocHandle`：之前调用 cuMemCreate 获得的 CUmemGenericAllocationHandle。
CUresult result = cuMemMap(ptr, size, 0, allocHandle, 0);

void setAccessOnDevice(int device, CUdeviceptr ptr, size_t size) {
    CUmemAccessDesc accessDesc = {};
    accessDesc.location.type = CU_MEM_LOCATION_TYPE_DEVICE;
    accessDesc.location.id = device;
    accessDesc.flags = CU_MEM_ACCESS_FLAGS_PROT_READWRITE;

    // 使地址可访问
    cuMemSetAccess(ptr, size, &accessDesc, 1);
}

cuMemUnmap(ptr, size);
cuMemRelease(handle);
cuMemAddressFree(ptr, size);

CUmemGenericAllocationHandle createMCHandle(int numDevices, size_t size) {
    CUmemAllocationProp mcProp = {};
    mcProp.numDevices = numDevices;
    mcProp.handleTypes = CU_MEM_HANDLE_TYPE_FABRIC; // 单节点也可以使用 CU_MEM_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR

    size_t granularity = 0;
    cuMulticastGetGranularity(&granularity, &mcProp, CU_MEM_ALLOC_GRANULARITY_MINIMUM);

    // 确保大小符合该分配的粒度要求
    size_t padded_size = ROUND_UP(size, granularity);

    mcProp.size = padded_size;

    // 创建多播对象；此时尚未关联设备和物理内存
    CUmemGenericAllocationHandle mcHandle;
    cuMulticastCreate(&mcHandle, &mcProp);

    return mcHandle;
}

cuMulticastAddDevice(&mcHandle, device);

cuMulticastBindMem(mcHandle, mcOffset, memHandle, memOffset, size, 0 /*flags*/);

__global__ void all_reduce_norm_barrier_kernel(float* l2_norm,
                                               float* partial_l2_norm_mc,
                                               unsigned int* arrival_counter_uc, unsigned int* arrival_counter_mc,
                                               const unsigned int expected_count) {
    assert( 1 == blockDim.x * blockDim.y * blockDim.z * gridDim.x * gridDim.y * gridDim.z );
    float l2_norm_sum = 0.0;
#if __CUDA_ARCH__ >= 900

    // 对所有副本执行原子归约
    // 概念上可以看作 __threadfence_system(); atomicAdd_system(arrival_counter_mc, 1);
    cuda::ptx::multimem_red(cuda::ptx::release_t, cuda::ptx::scope_sys_t, cuda::ptx::op_add_t, arrival_counter_mc, n);

    // 对同一内存 arrival_counter_uc 和 arrival_counter_mc 的 Multicast（mc）
    // 与 Unicast（uc）访问之间需要 fence：
    // - fence.proxy 指令在可能通过不同 proxy 发生的内存访问之间建立顺序；
    // - .proxykind 限定符的 .alias 值表示通过虚拟别名地址对同一内存位置执行的访问。
    // 参见 https://docs.nvidia.com/cuda/parallel-thread-execution/#parallel-synchronization-and-communication-instructions-membar
    cuda::ptx::fence_proxy_alias();

    // 使用 acquire 顺序在 UC 映射上自旋等待，直到所有对等端到达本次迭代
    // 注意：所有 rank 必须在此 kernel 后到达另一个屏障，以免某个 rank 较慢时，
    // 下一次迭代中某个 rank 的到达解除本次屏障。
    cuda::atomic_ref<unsigned int,cuda::thread_scope_system> ac(arrival_counter_uc);
    while (expected_count > ac.load(cuda::memory_order_acquire));

    // 从所有副本执行原子加载归约。它不提供排序，因此可以使用 relaxed。
    asm volatile ("multimem.ld_reduce.relaxed.sys.global.add.f32 %0, [%1];" : "=f"(l2_norm_sum) : "l"(partial_l2_norm_mc) : "memory");

#else
    #error "ERROR: multimem instructions require compute capability 9.0 or larger."
#endif

    *l2_norm = std::sqrt(l2_norm_sum);
}

int compressionSupported = 0;
cuDeviceGetAttribute(&compressionSupported, CU_DEVICE_ATTRIBUTE_GENERIC_COMPRESSION_SUPPORTED, device);

prop.allocFlags.compressionType = CU_MEM_ALLOCATION_COMP_GENERIC;

CUmemAllocationProp allocationProp = {};
cuMemGetAllocationPropertiesFromHandle(&allocationProp, allocationHandle);

if (allocationProp.allocFlags.compressionType == CU_MEM_ALLOCATION_COMP_GENERIC)
{
    // 获得了可压缩内存分配
}

__global__ void foo(char *A, char *B) {
  *A = 0x1;
  printf("%d\n", *B);    // 行为未定义！*B 可能取前一个值，
// 或者取介于两者之间的某个值。
}

__global__ void foo1(char *A) {
  *A = 0x1;
}

__global__ void foo2(char *B) {
  printf("%d\n", *B);    // *B == *A == 0x1，假设 foo2 等待 foo1
// 完成后才启动。
}

cudaMemcpyAsync(B, input, size, stream1);    // 允许在操作边界处使用别名
// 让 foo1 可以访问 A。
foo1<<<1,1,0,stream1>>>(A);
cudaEventRecord(event, stream1);
cudaStreamWaitEvent(stream2, event);
foo2<<<1,1,0,stream2>>>(B);
cudaStreamWaitEvent(stream3, event);
cudaMemcpyAsync(output, B, size, stream3);  // foo2 和 cudaMemcpy 都读取，
                                            // 二者都等待执行写入的 foo1
                                            // 完成后再继续。

__global__ void foo(char *A, char *B) {
  *A = 0x1;
  cuda::ptx::fence_proxy_alias();
  printf("%d\n", *B);    // *B == *A == 0x1
}

int deviceSupportsIpcHandle;
#if defined(__linux__)
    cuDeviceGetAttribute(&deviceSupportsIpcHandle, CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR_SUPPORTED, device));
#else
    cuDeviceGetAttribute(&deviceSupportsIpcHandle, CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_WIN32_HANDLE_SUPPORTED, device));
#endif

#if defined(__linux__)
    prop.requestedHandleTypes = CU_MEM_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR;
#else
    prop.requestedHandleTypes = CU_MEM_HANDLE_TYPE_WIN32;
    prop.win32HandleMetaData = // Windows 专用 LPSECURITYATTRIBUTES 属性。
#endif
